รหัสสินค้า | SKU-00151 |
หมวดหมู่ | ชุดปั๊มน้ำโซล่าเซลล์พร้อมแผง |
ราคา | 0.00 บาท |
สถานะสินค้า | พร้อมส่ง |
ลงสินค้า | 19 ต.ค. 2557 |
อัพเดทล่าสุด | 19 ต.ค. 2557 |
คงเหลือ | ไม่จำกัด |
จำนวน | ชิ้น |
ปั๊มน้ำพลังงานแสงอาทิตย์ ปั๊มน้ำโซล่าเซลล์15000ลิตรต่อชั่วโมง24V_DC pump 24V
รุ่น 1500GPH 24V+แผงโซล่าเซลล์ 250W ราคาพิเศษ
รุ่น 2000GPH 24V+แผงโซล่าเซลล์ 250W ราคาพิเศษ
รุ่น 3000GPH 24V+แผงโซล่าเซลล์ 300W ราคาพิเศษ
รุ่น 3500GPH 24V+แผงโซล่าเซลล์ 300W ราคาพิเศษ
|
Model |
Flow rate |
Volts |
Current |
Head |
Wire lead |
Outlet Dia |
N.W/G.W |
STCBP1-G1500-01 |
1500 GPH |
12V |
7.0A |
5 m |
1 m |
29 mm/1-1/8" |
1.13/1.21 kg |
|
STCBP2-G1500-01 |
1500 GPH |
24V |
5.0A |
5 m |
1 m |
29 mm/1-1/8" |
1.13/1.21 kg |
|
STCBP1-G2000-01 |
2000 GPH |
12V |
9.0A |
6 m |
1 m |
29 mm/1-1/8" |
1.13/1.21 kg |
|
STCBP2-G2000-01 |
2000 GPH |
24V |
5.5A |
6 m |
1 m |
29 mm/1-1/8" |
1.13/1.21 kg |
|
STCBP1-G3000-01 |
3000 GPH |
12V |
12.0A |
8 m |
1 m |
40 mm/1-1/2" |
2.10/2.37 kg |
|
STCBP2-G3000-01 |
3000 GPH |
24V |
7.0A |
8 m |
1 m |
40 mm/1-1/2" |
2.10/2.37 kg |
|
STCBP1-G3500-01 |
3500 GPH |
12V |
13.0A |
8 m |
1 m |
40 mm/1-1/2" |
2.10/2.37 kg |
|
STCBP2-G3500-01 |
3500 GPH |
24V |
8.0A |
8 m |
1 m |
40 mm/1-1/2" |
2.10/2.37 kg |
สามารถต่อแผงโซล่าเซลล์ได้โดยตรง หรือแบตเตอรี่
![]() |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
STANDARD PUMP CONFIGURATIONS
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
![]() |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Description | ||||
|
||||
Application: | ||||
![]() |
||||
How a Bilge Pump Works | ||||
Non-automatic bilge pumps offer traditional operation activated by a float or panel switch. Removal of the motor cartridge allows for easy cleaning of the strainer and impeller in the event that the pump becomes clogged with debris. Electric Submersible Pumps are by far the most popular type of electric Bilge Pumps, submersibles give very high outputs, are cost effective, have low amp draw and are easy to install. They are designed to fit in the lowest part of the bilge and only require discharge pipe work and electricity supply. |
