ปั๊มน้ำโซล่าเซลล์15000ลิตรต่อชั่วโมง24V_DC pump 24V

ปั๊มน้ำโซล่าเซลล์15000ลิตรต่อชั่วโมง24V_DC pump 24V
รหัสสินค้า SKU-00151
หมวดหมู่ ชุดปั๊มน้ำโซล่าเซลล์พร้อมแผง
ราคา 0.00 บาท
สถานะสินค้า พร้อมส่ง
ลงสินค้า 19 ต.ค. 2557
อัพเดทล่าสุด 19 ต.ค. 2557
คงเหลือ ไม่จำกัด
จำนวน
ชิ้น
หยิบลงตะกร้า
บัตรประชาชน
บุ๊คแบ๊งค์
คุ้มครองโดย LnwPay

ปั๊มน้ำพลังงานแสงอาทิตย์ ปั๊มน้ำโซล่าเซลล์15000ลิตรต่อชั่วโมง24V_DC pump 24V

รุ่น 1500GPH 24V+แผงโซล่าเซลล์ 250W ราคาพิเศษ

รุ่น 2000GPH 24V+แผงโซล่าเซลล์ 250W ราคาพิเศษ

รุ่น 3000GPH 24V+แผงโซล่าเซลล์ 300W ราคาพิเศษ

รุ่น 3500GPH 24V+แผงโซล่าเซลล์ 300W ราคาพิเศษ



Model

Flow rate

Volts

Current

Head

Wire lead

Outlet Dia

N.W/G.W

STCBP1-G1500-01

1500 GPH

12V

7.0A

5 m

1 m

29 mm/1-1/8"

1.13/1.21 kg

STCBP2-G1500-01

1500 GPH

24V

5.0A

5 m

1 m

29 mm/1-1/8"

1.13/1.21 kg

STCBP1-G2000-01

2000 GPH

12V

9.0A

6 m

1 m

29 mm/1-1/8"

1.13/1.21 kg

STCBP2-G2000-01

2000 GPH

24V

5.5A

6 m

1 m

29 mm/1-1/8"

1.13/1.21 kg

STCBP1-G3000-01

3000 GPH

12V

12.0A

8 m

1 m

40 mm/1-1/2"

2.10/2.37 kg

STCBP2-G3000-01

3000 GPH

24V

7.0A

8 m

1 m

40 mm/1-1/2"

2.10/2.37 kg

STCBP1-G3500-01

3500 GPH

12V

13.0A

8 m

1 m

40 mm/1-1/2"

2.10/2.37 kg

STCBP2-G3500-01

3500 GPH

24V

8.0A

8 m

1 m

40 mm/1-1/2"

2.10/2.37 kg

สามารถต่อแผงโซล่าเซลล์ได้โดยตรง หรือแบตเตอรี่







STANDARD PUMP CONFIGURATIONS



Model

Flow rate

Volts

Current

Head

Wire lead

Outlet Dia

N.W/G.W

STCBP1-G1500-01

1500 GPH

12V

7.0A

5 m

1 m

29 mm/1-1/8"

1.13/1.21 kg

STCBP2-G1500-01

1500 GPH

24V

5.0A

5 m

1 m

29 mm/1-1/8"

1.13/1.21 kg

STCBP1-G2000-01

2000 GPH

12V

9.0A

6 m

1 m

29 mm/1-1/8"

1.13/1.21 kg

STCBP2-G2000-01

2000 GPH

24V

5.5A

6 m

1 m

29 mm/1-1/8"

1.13/1.21 kg

STCBP1-G3000-01

3000 GPH

12V

12.0A

8 m

1 m

40 mm/1-1/2"

2.10/2.37 kg

STCBP2-G3000-01

3000 GPH

24V

7.0A

8 m

1 m

40 mm/1-1/2"

2.10/2.37 kg

STCBP1-G3500-01

3500 GPH

12V

13.0A

8 m

1 m

40 mm/1-1/2"

2.10/2.37 kg

STCBP2-G3500-01

3500 GPH

24V

8.0A

8 m

1 m

40 mm/1-1/2"

2.10/2.37 kg













Product Description
  • Heavy duty motors with stainless steel shafts and tough thermoplastic bodies.
  • Totally submersible and ignition protected.
  • To all existing safety standards.
  • Water cooled motors for long life, with anti airlock design and moisture tight seals.
  • Snap-lock strainer base for easy installation and removal, and silent vibration free running
  • Includes comprehensive user manual with installation instructions and wiring diagram



   Application:
  • Typically used in boat hulls / bilges
  • Bait tanks
  • Ponds, pools, spas
  • Other applications where you have to remove water from
  • Note: These pumps are designed for intermittent use only, NOT designed for continuous use


 How a Bilge Pump Works

Non-automatic bilge pumps offer traditional operation activated by a float or panel switch. Removal of the motor cartridge allows for easy cleaning of the strainer and impeller in the event that the pump becomes clogged with debris. Electric Submersible Pumps are by far the most popular type of electric Bilge Pumps, submersibles give very high outputs, are cost effective, have low amp draw and are easy to install. They are designed to fit in the lowest part of the bilge and only require discharge pipe work and electricity supply.
